Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers

    Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers

    Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers
    • Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers
    • Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers
    • Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers
    • Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers
    • Buy cheap Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers from wholesalers

    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers

    Ask Lasest Price
    Brand Name : HAOZHIYUE
    Model Number : HZY-50
    Certification : CCS/BV/LR/IRS/IACS
    Supply Ability : 30pcs/month
    Delivery Time : 5~8 working days
    • Product Details
    • Company Profile

    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers

    Pneumatic boat rubber fender yokohama type floating marine fender

    Product Overview

    The following factors should be considered in the selection of pneumatic fenders:

    (1) Maximum energy absorption E; (2) Reaction force; (3) Distance requirements after berthing of two ships or the berthing distance from the ship to the dock, including the maximum distance and the minimum distance; (4) The size of the ship; (5) Factors such as wind waves and temperature changes in the actual use environment.
    The selection of pneumatic fender system first needs to determine the collision energy of the ship when berthing and after berthing, and select the specifications of pneumatic fender according to the distance requirements (maximum distance and minimum distance) after berthing, and verify whether the maximum reaction force of pneumatic fender is within the allowable range of hull design.
    If it is necessary to improve the energy absorption of the pneumatic fender, increasing its diameter is an ideal choice. The number and spacing of pneumatic fenders are determined according to the size and actual use of the ship.
    Yokohama pneumatic marine rubber fender can be delivered in various sizes and types. Chain and tyre net (CTN) type is usually recommended to protect the fender body, but sling type or body only is also available.

    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers

    1.Outer Rubber
    Cover outside on the ball of rubber layer, which is used to protect skeleton material and inner rubber ball from damage of external force.
    2.Cord layers
    Reinforced cord rubber layer is composed of winding synthetic cord layer, it is mainly used for maintain the internal air pressure.
    3. Inner Rubber
    On the ball inside the rubber layer, which is used to prevent air leakage and control the ball pressure.
    4. End Flange
    The metal parts at both ends of fender, which can be fitted with charging valve and safety valve.
    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy BumpersPneumatic Marine Rubber Fenders Yokohama Black Boat Buoy BumpersPneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers
    Our Advantages

    Why choose HAOZHIYUE pneumatic rubber fender?

    1.Learder since 1992, with more than 20 years produce experience;

    2.Best quality with 3 years guarantee period;

    3.Comply with ISO17357:2002;

    4.Certificates BV,CCS,LR,IRS etc available;

    5.Customized different dimention according to requirements;

    6.Lifespan more than 10 years;

    7.Different dimension stocks, the delivery time can be within 3 days;

    8.Can be deflated in transit.

    9.Long time good after-sale service;

    10.Professional engineer recommend suitable dimension and quantity of rubber fender.


    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers


    Specification

    Specification and Performance of pneumatic marine rubber fender

    Specification (D×L)m*mInitial pressure 50kPaInitial pressure 80kPa
    Reaction force (kN)Energy absorption (KJ)Reaction force (kN)Energy absorption (KJ)
    0.5×1.0646858
    0.6×1.07489811
    0.7×1.51371718024
    1.0×1.51823223945
    1.0×2.02574533863
    1.2×2.02976339088
    1.35×2.5427102561142
    1.5×3.0597153761214
    1.7×3.0639191840267
    2.0×3.58753081150430
    2.5×4.013816631815925
    2.5×5.5201994326531317
    3.3×4.51884117524761640
    3.3×6.53015181439612532
    4.5x9.05747475275516633


    Yokohama Pneumatic rubber fender are available from 500X1000mm to 3300X6500mm, including all the standard and no-standard specifications.

    All the relevant metal accessories of pneuamtic fenders, include shackles, towing rings, swivels, chain net, are made of stainless steel, and H.D.G. which are resistant for sea water corrosion.

    Structure

    ---Material


    Material of airbag_


    ---Accessories(All accessories is stainless steel or hot dip galvanizing):



    ---BV Inspection:


    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers


    ---Productive Process:

    Certifications

    Delivery

    Pneumatic Marine Rubber Fenders Yokohama Black Boat Buoy Bumpers


    Certificate of CCS,ABS,GL.BV,DNV etc is available<<<<


    FAQ

    1. Q:Whats the guarantee for your products?

    A:Guarantee period for our product is 3 years, during this period, except man-made damage, we will repair or exchange new one for free.

    2. Q: Do you have stocks? In which size?

    A:Yes, we have some normal size in stocks,for example dia1.2m,dia1.5m,dia2.5m,other size pls confirm with our company directly.

    3. Q:Are you manufacturer or trading company?

    A: We are manufacturer in this field for more than 20 years, with rich produce experience.

    4. Q:We dont know which size is suitable,can you help me?

    A:No problem,pls tell us information about your ship, our engineer will recommend suitable size for you.

    5. Q:Whats the delivery time?

    A: Usually within 3 days after receive payment.

    6. Q:Whats your payment term?

    A:T/T or L/C at sight

    7. Q: Whats your MOQ?

    A: 1 PC.

    8.Q: What’s the material of your products ?

    A: the main raw materials are natural rubber, synthetic-tyre-cord fabric and customized hardwares, etc.

    9.Q: Is OEM service available ?

    A: yes
